Neuroanatomy II

2025-09-09

Rick Gilmore

Department of Psychology

Prelude

Suprachiasmatic nucleus (SCN)

McGee (2011)

Today’s topics

  • Announcement
  • Warm up
  • Wrap up on functional methods
  • Anatomy of the brain

Announcement

  • Quiz 1 next time

Warm up

Which of the following structures are not part of the hindbrain?

  • A. 4th ventricle
  • B. Tectum
  • C. Medulla oblongata
  • D. Pons

Which of the following structures are not part of the hindbrain?

  • A. 4th ventricle
  • B. Tectum
  • C. Medulla oblongata
  • D. Pons

What plane of section does this image represent?

  • A. Dorsal
  • B. Sagittal
  • C. Axial
  • D. Coronal/Frontal

What plane of section does this image represent?

  • A. Dorsal
  • B. Sagittal
  • C. Axial
  • D. Coronal/Frontal

What’s inside the cerebral ventricles?

  • A. Nothing
  • B. Cerebrospinal Fluid (CSF)
  • C. We don’t know because we can’t measure it
  • D. Oxygenated blood

What’s inside the cerebral ventricles?

  • A. Nothing
  • B. Cerebrospinal Fluid (CSF)
  • C. We don’t know because we can’t measure it
  • D. Oxygenated blood

Anatomy of the brain

Organization of the brain

Major division Ventricular Landmark Embryonic Division Structure
Forebrain Lateral Telencephalon Cerebral cortex
Basal ganglia
Hippocampus, Amygdala

Organization of the brain

Major division Ventricular Landmark Embryonic Division Structure
Third Diencephalon Thalamus
Hypothalamus
Midbrain Cerebral Aqueduct Mesencephalon Tectum, Tegmentum

Organization of the brain

Major division Ventricular Landmark Embryonic Division Structure
Hindbrain 4th Rhombencephalon Cerebellum, pons
Medulla oblongata

Diencephalon (“between” brain)

  • Thalamus
  • Hypothalamus

Thalamus

  • Input to cortex
  • Functionally distinct nuclei (collection of neurons)
    • Lateral geniculate nucleus (LGN), vision
    • Medial geniculate nucleus (MGN), audition

Hypothalamus

  • Five Fs: fighting, fleeing/freezing, feeding, and reproduction
  • Controls Autonomic Nervous System (ANS)
    • Sympathetic branch
    • Parasympathetic branch

Hypothalamus

  • Controls endocrine system via pituitary gland (“master” gland)
    • Anterior pituitary (indirect release of hormones)
    • Posterior (direct release of hormones)
      • Oxytocin
      • Vasopressin

Hypothalamus

  • Regulates circadian rhythms (via Suprachiasmatic Nucleus)

https://en.wikipedia.org/wiki/Hypothalamus

Telencephalon

  • Basal (not basil!) ganglia
  • Hippocampus
  • Amygdala
  • Cerebral cortex

Basal ganglia

  • Skill and habit learning
  • Sequencing of movement
  • Example: Parkinson’s Disease

Basal ganglia

Basal ganglia

Hippocampus

  • From Greek for “sea horse”

Hippocampus

  • Immediately lateral to (inferior) lateral ventricles
  • Medial temporal lobe
  • Memories of specific facts or events, spatial locations
  • Implicated in Alzheimer’s Disease

Hippocampus

https://en.wikipedia.org/wiki/Hippocampus

Amygdala

  • “almond”-shaped
  • Influences physiological state, behavioral readiness, affect
  • NOT the fear center! (LeDoux, 2015).

Cerebral Cortex

Hemispheres

Landmarks

Landmark Identifies/separates
Medial longitudinal fissure (longitudinal fissure) Divides hemispheres
Lateral sulcus/fissure aka Sylvian Fissure Divides temporal lobe from frontal & parietal
Central sulcus aka Rolandic Fissure Divides frontal from parietal lobe

(Medial) Longitudinal fissure

Wikipedia

Corpus Callosum

  • Axon (fiber) bundle
  • Bottom of longitudinal fissure
  • Connects left and right hemispheres
  • Part of “roof” of lateral ventricles

Wikipedia contributors (2025)

Lateral sulcus/fissure

https://en.wikipedia.org/wiki/Lateral_sulcus

Central sulcus

https://en.wikipedia.org/wiki/Central_sulcus

Lobes of the Cerebral Cortex

Frontal lobe

  • Where is it?
    • Anterior to central sulcus
    • Superior to lateral fissure
    • Dorsal to temporal lobe

Frontal lobe

Frontal lobe

  • What does it do/contain?
    • Prefrontal cortex
      • Planning, problem solving, working memory…?
    • Primary olfactory cortex
    • Gustatory cortex
    • Anterior cingulate cortex (ACC)

Temporal lobe

  • Where is it?
    • Ventral to frontal, parietal lobes
    • Inferior to lateral fissure

Temporal lobe

Parietal lobe

  • Where is it?
    • Caudal to frontal lobe
    • Dorsal to temporal lobe
    • Posterior to central sulcus

Parietal lobe

  • What does it do/contain?

Parietal lobe

Occipital lobe

Occipital lobe

  • Multiple visual areas in occipital lobe

Insular cortex (insula)

  • Where is it?
    • medial to temporal lobe
    • deep inside lateral fissure

Insular cortex (insula)

  • What does it do/contain?
    • Primary gustatory cortex
    • self-awareness, interpersonal experiences, motor control

Namkung, Kim, & Sawa (2018)

Summary: Lobes, landmarks, areas

Lobe Sulci Gyri Areas
Frontal Central sulcus Precentral gyrus motor cortex
Corpus callosum Cingulate gyrus anterior cingulate cortex
olfactory cortex
gustatory cortex
Lobe Sulci Gyri Areas
Temporal Lateral fissure auditory cortex
olfactory cortex
hipppocampus
amygdala
Lobe Sulci Gyri Areas
Parietal Central sulcus Postcentral gyrus somatosensory ctx
Occipital visual ctx
Insula Lateral fissure gustatory ctx

Brodmann Areas

  • Regions of cerebral cortex that differ in cellular architecture.
  • Korbinian Brodmann

Brodmann areas

  • Sequential (arbitrary) numbering scheme
  • Brodmann Area (BA) 4: precentral gyrus of frontal lobe (M1)
  • BA 17 and 18: Primary visual cortex (V1) in occipital lobe

Simply Psychology

Next time

  • Quiz 1 (15-20 min)
  • Neuroanatomy III
    • Spinal cord
    • Peripheral Nervous System (PNS)
